Software · Quality Control
Dimensional Inspection Software
Dimensional inspection software — measure geometry and GD&T against CAD from scan data, with deviation maps and traceable inspection reports.
CAD deviationGD&TFirst-articleTraceable reports
10 products
Brands: Geomagic · PolyWorks · Shining 3D
Ships from Auburn Hills, MI
Featured in Dimensional Inspection
10 products · 3 brands
Shining 3D
SHINING3D Inspect
Contact for quote
PolyWorks
PolyWorks Inspector — Universal 3D Metrology Software
Contact for quote
PolyWorks
PolyWorks Reviewer
Contact for quote
PolyWorks
PolyWorks DataLoop
Contact for quote
PolyWorks
PolyWorks PMI+Loop
Contact for quote
PolyWorks
PolyWorks AR
$1,500
In stock
PolyWorks
PolyWorks ReportLoop
Contact for quote
PolyWorks
PolyWorks Talisman
Contact for quote
Geomagic
Geomagic Control X
$5,520
In stock
Shining 3D
SHINING 3D EXMeasure Dimensional Inspection Software
$699
In stock
What is dimensional inspection software?
Dimensional inspection software measures a part's geometry against its CAD model and drawing — distances, GD&T callouts, and tolerances — from scan or probe data, producing color deviation maps and traceable reports.
What it checks
CAD compareWhole-part deviation from nominal geometry.
GD&TFlatness, position, profile, and more to callout.
ReportingFirst-article (AS9102-style) and in-process reports.
Where it fits
- First-article inspection for aerospace, auto, and medical.
- In-process and incoming quality checks.
- Supplier qualification and audit documentation.
Inspection software, supported in the USA
Rev1 resells and supports dimensional inspection tools. Rev1 Technologies is your US reseller and support partner in Auburn Hills, Michigan — real people who use this gear, fast domestic shipping, no customs wait. Use the brand filter to narrow the range, or call (248) 707-2950 for help choosing.
