Smaller diameter extrudes thin filaments
High resolution on the horizontal print surface
0.6mm and 0.8mm Nozzle – Faster Print Speed
Larger diameter extrudes more filaments per second, resulting in faster print speed
Comparison of Different Nozzle Sizes
0.2 mm Nozzle
0.4 mm Nozzle
0.6 mm Nozzle
0.8 mm Nozzle
Usage scenario
Perfect for small and
intricate models, with precision
thats worth the wait
Ideal for everyday use
with the perfect balance
of speed and qualty
Faster speeds and capable
of printing high-performance filaments,
with some decrease in resolution
Faster speeds and capable
of printing high-performance filaments,
with some decrease in resolution
Commonly used for
Miniature models
Intricate logos
Text
Molds
Toys
Mechanical parts
Decorative objects
Large structural parts
Functional parts for household
Industrial or engineering parts
High-strength models
Large structural parts
Functional parts for household
Industrial or engineering parts
High-strength models
*The final display of ‘Model Strength’ & ‘Model Fineness’ depend on the results of the material testing.
Filament Compatibility
Material
0.2 mm Nozzle
0.4 mm Nozzle
0.6 mm Nozzle
0.8 mm Nozzle
Hardened Steel Required?
General PLA
YES
YES
YES
YES
Optional
PLA Sparkle
*NO
YES
YES
YES
Optional
PLA Marble
*NO
YES
YES
YES
Optional
Wood/Rock/Metal-filled PLA
*NO
YES
YES
YES
Optional
PETG
YES
YES
YES
YES
Optional
PVA
YES
YES
YES
YES
Optional
ABS
YES
YES
YES
YES
Optional
ASA
YES
YES
YES
YES
Optional
PC
YES
YES
YES
YES
Optional
PA
*NO
YES
YES
YES
Optional
TPU
*NO
YES
YES
YES
Optional
Bambu PLA-CF
*NO
*Highly
Recommended
YES
YES
*Required
Bambu PETG-CF
*NO
*Highly
Recommended
YES
YES
*Required
Bambu PAHT-CF
*NO
YES
*Highly
Recommended
YES
*Required
Bambu PET-CF
*NO
YES
*Highly
Recommended
YES
*Required
CF/GF Filaments from other brands
*NO
Not Recommended
YES
YES
*Required
[*Note]
Filaments with carbon fiber, glass fiber, metal, or other inorganic particles are prone to clog a 0.2 mm nozzle.
For filaments containing carbon fiber or glass fiber, it is highly recommended to use a hardened steel0.6 mm nozzleto minimize the risk of clogging and abrasion.
Bambu PLA-CF andBambu PETG-CF have been extensively tested and proven to have a low risk of clogging when printed with a hardened steel 0.4 mm nozzle, while also achieving higher print quality.
Learn more about filament compatibility on Bambu Lab Wiki.
Replacing Complete Hotend
Replacing Hotend
Learn more about replacing the Complete Hotend and Hotend on Bambu Lab Wiki.
