CreatBotF430 NX Y DriveGenuine CreatBot Replacement Part
F430 NX Y Drive V2 (Y-Axis Stepper Driver)
The CreatBot F430 NX Y drive V2 (part 115009) is the OEM stepper motor driver for the Y axis of the CreatBot F430 NX 3D printer. CreatBot names it V2, the current version of this Y-axis driver. The driver receives step and direction commands from the main control board and supplies the current that turns the Y motor, moving the print front to back. If the Y drive loses steps or cuts out, the print shifts and the part is usually lost. Full specifications →
Genuine CreatBot part, shipped from Rev1 — your authorized CreatBot dealer and service partner. Not sure it fits? Call (248) 707-2950.
Genuine CreatBot F430 NX Y Drive, from an authorized CreatBot dealer.
An authentic CreatBot replacement part, not a third-party copy. Rev1 Technologies is an authorized CreatBot dealer and certified CreatBot service provider in Auburn Hills, Michigan.
Signs the Y drive may need replacing
Layers shift front to back partway through a print.
The Y axis will not home, or crashes at the end of travel.
The Y motor hums, vibrates or stutters instead of moving smoothly.
The Y motor works correctly when tested from a known good driver channel.
Check belt tension, pulley set screws and the Y motor cable before replacing the driver. Many Y axis shifts are mechanical.
Compatible CreatBot 3D printer
The other F430 NX drivers are the X/Z drive (115007) and the E drive (115011).
About the V2 designation
CreatBot supplies this Y drive as V2. If your F430 NX has an earlier Y driver fitted, contact Rev1 with a photo of the existing module and we will confirm the replacement before it ships.
Installation tips
Power the printer off and unplug it before you open the electronics enclosure. Photograph the old driver to record its orientation, fit the new one the same way round and reconnect the Y motor cable. Home the printer and run a test print that uses the full depth of the bed.
CreatBot F430 NX Y Drive Specifications
WHY REV1 TECH
Sold and Supported by Rev1 Technologies
Rev1 Technologies is an authorized CreatBot dealer and certified CreatBot service provider in the US. Not sure which part your printer needs? Send us your printer model and serial number and our team will confirm the right part before it ships. We also handle installation, repair and preventive maintenance on CreatBot printers.
CreatBot F430 NX Y Drive — Questions
Does the F430 NX use the same driver for X and Y?
No. CreatBot lists the X/Z drive as part 115007 and the Y drive V2 as part 115009.
Will it fit my F430?
Part 115009 is listed for the F430 NX only.
Is this a genuine CreatBot part?
Yes, CreatBot part 115009, supplied by Rev1 Technologies, an authorized CreatBot dealer and certified service provider.
Is this a genuine CreatBot part?
Yes. Rev1 Technologies is an authorized CreatBot dealer and certified CreatBot service provider in the US, and every part we sell is a genuine CreatBot part.
How do I confirm it fits my printer?
Send us your printer model and serial number, or call (248) 707-2950, and our team will confirm the right part before it ships.
Can Rev1 install it for me?
Yes. We handle installation, repair and preventive maintenance on CreatBot printers. Ask us about on-site or depot service.
