CreatBotD600 Pro2 X Axis MotorGenuine CreatBot Replacement Part
D600 Pro2 X Axis Motor for D600 Pro2 HS
The CreatBot D600 Pro2 X motor (part 132008) is an OEM X axis motor that CreatBot lists for the D600 Pro2 HS 3D printer. The X axis carries the print head across the gantry, so this motor sets the accuracy of every line the printer lays down in that direction. When it starts to fail, the first signs are usually layer shifts, noise or an axis that refuses to home. Full specifications →
Genuine CreatBot part, shipped from Rev1 — your authorized CreatBot dealer and service partner. Not sure it fits? Call (248) 707-2950.
Genuine CreatBot D600 Pro2 X Axis Motor, from an authorized CreatBot dealer.
An authentic CreatBot replacement part, not a third-party copy. Rev1 Technologies is an authorized CreatBot dealer and certified CreatBot service provider in Auburn Hills, Michigan.
Signs the X motor needs replacing
Layers step sideways in X partway through a print.
The print head moves unevenly or makes a clicking or grinding sound.
The X axis does not reach its home position, or stops while other axes keep moving.
The motor is unusually hot after normal printing.
Belt tension, pulley set screws and the motor cable should be checked first. If the problem stays with the motor, a genuine replacement is the fix.
Which X motor does my D600 Pro2 HS use?
CreatBot lists two X motors for the D600 Pro2 HS: this motor, part 132008, and the X closed-loop motor, part 132001. They are not interchangeable without checking, so compare against the motor in your printer or send Rev1 your serial number and a photo of the motor label. We will confirm the correct part before you order.
Compatible CreatBot 3D printer
The matching Y motor is part 132009. The D600 Pro uses different motors (X 132006, Y 132007).
Installation tips
Disconnect power before opening the printer. Photograph the cable routing, release the X belt tension and remove the old motor. Move the pulley across if needed, keeping it at the same position on the shaft so the belt tracks straight. Re-tension, home the printer and print a test part with long X moves.
CreatBot D600 Pro2 X Axis Motor Specifications
WHY REV1 TECH
Sold and Supported by Rev1 Technologies
Rev1 Technologies is an authorized CreatBot dealer and certified CreatBot service provider in the US. Not sure which part your printer needs? Send us your printer model and serial number and our team will confirm the right part before it ships. We also handle installation, repair and preventive maintenance on CreatBot printers.
CreatBot D600 Pro2 X Axis Motor — Questions
Is this the same as the closed-loop X motor?
No. The closed-loop X motor is a separate part, 132001. Rev1 can confirm which one your D600 Pro2 HS needs.
Does it fit the D600 Pro?
No. The D600 Pro uses X motor 132006.
Is it a genuine CreatBot part?
Yes, part 132008, supplied by Rev1 Technologies, an authorized CreatBot dealer.
Is this a genuine CreatBot part?
Yes. Rev1 Technologies is an authorized CreatBot dealer and certified CreatBot service provider in the US, and every part we sell is a genuine CreatBot part.
How do I confirm it fits my printer?
Send us your printer model and serial number, or call (248) 707-2950, and our team will confirm the right part before it ships.
Can Rev1 install it for me?
Yes. We handle installation, repair and preventive maintenance on CreatBot printers. Ask us about on-site or depot service.
