CreatBotD600 Pro Y Axis MotorGenuine CreatBot Replacement Part
For the CreatBot D600 Pro
The CreatBot D600 Pro Y motor (part 132007) is the OEM Y axis motor for the CreatBot D600 Pro 3D printer. It drives the front to back motion of the machine. When the Y motor starts losing position, you see it as a sudden offset in the part, usually on one layer, and everything printed above that layer is misaligned. Replacing a failing motor with the genuine part brings the axis back to the way it worked when the printer was new. Full specifications →
Genuine CreatBot part, shipped from Rev1 — your authorized CreatBot dealer and service partner. Not sure it fits? Call (248) 707-2950.
Genuine CreatBot D600 Pro Y Axis Motor, from an authorized CreatBot dealer.
An authentic CreatBot replacement part, not a third-party copy. Rev1 Technologies is an authorized CreatBot dealer and certified CreatBot service provider in Auburn Hills, Michigan.
Signs the Y motor needs replacing
Front to back layer shifts that are not explained by belt tension or a collision.
Grinding, buzzing or stuttering from the Y motor during fast travel.
The Y axis does not home, or stops while the X axis keeps moving.
Rough or notchy rotation when the shaft is turned by hand with the power off.
Check the Y belt, the pulley set screws and the cable connection first. If the fault follows the motor, order a replacement. Rev1 support can talk you through the checks.
Compatible CreatBot 3D printer
The X axis on the D600 Pro uses part 132006. The D600 Pro2 HS uses its own Y motors, parts 132002 and 132009.
Installation tips
Power the printer off and unplug it. Photograph the motor connector and cable routing, then slacken the Y belt and remove the motor. Mount the new motor the same way round, align the pulley with the belt path and tighten its set screws firmly. Re-tension the belt, home all axes and print a square calibration part to confirm the Y size is correct.
CreatBot D600 Pro Y Axis Motor Specifications
WHY REV1 TECH
Sold and Supported by Rev1 Technologies
Rev1 Technologies is an authorized CreatBot dealer and certified CreatBot service provider in the US. Not sure which part your printer needs? Send us your printer model and serial number and our team will confirm the right part before it ships. We also handle installation, repair and preventive maintenance on CreatBot printers.
CreatBot D600 Pro Y Axis Motor — Questions
Can I swap the X and Y motors on the D600 Pro?
Order the part listed for each axis. CreatBot lists the Y motor as 132007 and the X motor as 132006.
Is this a genuine CreatBot motor?
Yes. It is part 132007, supplied by Rev1 Technologies, an authorized CreatBot dealer.
My printer is still under warranty. What should I do?
Contact Rev1 first. As a certified CreatBot service provider we can diagnose the fault and handle the replacement.
Is this a genuine CreatBot part?
Yes. Rev1 Technologies is an authorized CreatBot dealer and certified CreatBot service provider in the US, and every part we sell is a genuine CreatBot part.
How do I confirm it fits my printer?
Send us your printer model and serial number, or call (248) 707-2950, and our team will confirm the right part before it ships.
Can Rev1 install it for me?
Yes. We handle installation, repair and preventive maintenance on CreatBot printers. Ask us about on-site or depot service.
