CreatBotD1000 Pro HS Y-Axis Motor DriveGenuine CreatBot Replacement Part
For the CreatBot D1000 Pro HS
The CreatBot D1000 Pro HS Y-axis motor drive (part 115020) is the OEM stepper motor driver for the Y axis of the CreatBot D1000 Pro HS. Every front to back move the printer makes runs through this module. The main control board sends step and direction commands, and the driver supplies the matched current that turns the Y motor. When a driver starts to fail, prints show it as shifted layers, skipped steps or an axis that stops responding. Full specifications →
Genuine CreatBot part, shipped from Rev1 — your authorized CreatBot dealer and service partner. Not sure it fits? Call (248) 707-2950.
Genuine CreatBot D1000 Pro HS Y-Axis Motor Drive, from an authorized CreatBot dealer.
An authentic CreatBot replacement part, not a third-party copy. Rev1 Technologies is an authorized CreatBot dealer and certified CreatBot service provider in Auburn Hills, Michigan.
Why replace with the genuine part
The same driver module the printer was designed and tuned around.
Same connectors and mounting, so no rewiring.
CreatBot lists separate X and Y drivers for this model, so you replace exactly what failed.
Signs the Y-axis drive may need replacing
Front to back layer shifts with good belt tension and tight pulleys.
The Y motor buzzes, stalls or will not home.
The Y motor runs normally from a known good driver, but not from this one.
Compatible CreatBot 3D printer
The matching X-axis motor drive for the D1000 Pro HS is part 115019. The earlier D1000 HS uses a different Y drive, part 115004.
Installation tips
Switch off and unplug the printer. Photograph the driver and cable positions, remove the old module and fit the new one in the same orientation. Reconnect the Y motor cable, home the printer and run a test print that covers the full depth of the bed.
CreatBot D1000 Pro HS Y-Axis Motor Drive Specifications
WHY REV1 TECH
Sold and Supported by Rev1 Technologies
Rev1 Technologies is an authorized CreatBot dealer and certified CreatBot service provider in the US. Not sure which part your printer needs? Send us your printer model and serial number and our team will confirm the right part before it ships. We also handle installation, repair and preventive maintenance on CreatBot printers.
CreatBot D1000 Pro HS Y-Axis Motor Drive — Questions
Will it fit my D1000 HS?
No. The D1000 HS uses Y drive part 115004. Part 115020 is for the D1000 Pro HS.
Can I swap the X and Y drivers to test?
Moving a motor cable to a known good channel is a common way to isolate a fault. Power the printer off before you change any connection.
Can Rev1 do the repair?
Yes. Rev1 Technologies is a certified CreatBot service provider and can diagnose and replace the driver.
Is this a genuine CreatBot part?
Yes. Rev1 Technologies is an authorized CreatBot dealer and certified CreatBot service provider in the US, and every part we sell is a genuine CreatBot part.
How do I confirm it fits my printer?
Send us your printer model and serial number, or call (248) 707-2950, and our team will confirm the right part before it ships.
Can Rev1 install it for me?
Yes. We handle installation, repair and preventive maintenance on CreatBot printers. Ask us about on-site or depot service.
