CreatBotD1000 HS Auto-Rising ServoGenuine CreatBot Replacement Part
D1000 HS Auto-Rising Servo for D1000 HS and D1000
The CreatBot D1000 HS servo for auto-rising (part 133003) is the OEM servo that operates the nozzle auto-rising system on the CreatBot D1000 HS, and CreatBot also lists it for the D1000. On a dual extruder CreatBot, the auto-rising system lifts the nozzle that is not printing so it stays clear of the part. Without it, the idle nozzle can drag across fresh layers, leave ooze and scars on the surface, or knock a tall print loose. Full specifications →
Genuine CreatBot part, shipped from Rev1 — your authorized CreatBot dealer and service partner. Not sure it fits? Call (248) 707-2950.
Genuine CreatBot D1000 HS Auto-Rising Servo, from an authorized CreatBot dealer.
An authentic CreatBot replacement part, not a third-party copy. Rev1 Technologies is an authorized CreatBot dealer and certified CreatBot service provider in Auburn Hills, Michigan.
Signs the auto-rising servo needs replacing
The idle nozzle no longer lifts, or only lifts part of the way.
Dual material or dual color prints show scraping marks and blobs where the inactive nozzle touches the part.
The servo twitches, buzzes or chatters instead of moving cleanly.
Tool changes are inconsistent, with the nozzle sitting at different heights from one change to the next.
Compatible CreatBot 3D printers
For the D1000, CreatBot also lists auto-rising servo 133011, and the general auto-rising servo 133013 is listed for the D1000 HS. If you are not sure which servo is in your machine, send Rev1 a photo and your serial number. The bed leveling servo is a different part: 133004 on the D1000 HS and 133007 on the D1000.
Installation tips
Power the printer off and let the hotends cool before working around the print head. Photograph the servo connector and the linkage position, then remove the old servo and fit the new one in the same orientation. Reconnect the cable and route it away from heated parts and moving belts. Afterward, check that the idle nozzle lifts fully and that both nozzles return to the correct printing height, then run a dual extrusion test print.
CreatBot D1000 HS Auto-Rising Servo Specifications
WHY REV1 TECH
Sold and Supported by Rev1 Technologies
Rev1 Technologies is an authorized CreatBot dealer and certified CreatBot service provider in the US. Not sure which part your printer needs? Send us your printer model and serial number and our team will confirm the right part before it ships. We also handle installation, repair and preventive maintenance on CreatBot printers.
CreatBot D1000 HS Auto-Rising Servo — Questions
Is this the same as the bed leveling servo?
No. The auto-rising servo lifts the idle nozzle. Bed leveling uses its own servo, part 133004 on the D1000 HS.
Does it fit my D1000?
Yes. CreatBot lists part 133003 for both the D1000 HS and the D1000.
Is this a genuine CreatBot part?
Yes, part 133003, supplied by Rev1 Technologies, an authorized CreatBot dealer.
Is this a genuine CreatBot part?
Yes. Rev1 Technologies is an authorized CreatBot dealer and certified CreatBot service provider in the US, and every part we sell is a genuine CreatBot part.
How do I confirm it fits my printer?
Send us your printer model and serial number, or call (248) 707-2950, and our team will confirm the right part before it ships.
Can Rev1 install it for me?
Yes. We handle installation, repair and preventive maintenance on CreatBot printers. Ask us about on-site or depot service.
