0.2mm Nozzle – Optimal Print Fineness
Smaller diameter extrudes thin filaments
High resolution on the horizontal print surface
0.6mm and 0.8mm Nozzle – Faster Print Speed
Larger diameter extrudes more filaments per second, resulting in faster print speed
Comparison of Different Nozzle Sizes
|
0.2 mm Nozzle |
0.4 mm Nozzle |
0.6 mm Nozzle |
0.8 mm Nozzle |
Usage scenario |
Perfect for small and intricate models, with precision thats worth the wait |
Ideal for everyday use with the perfect balance of speed and qualty |
Faster speeds and capable of printing high-performance filaments, with some decrease in resolution |
Faster speeds and capable of printing high-performance filaments, with some decrease in resolution |
Commonly used for |
Miniature models Intricate logos Text Molds |
Toys Mechanical parts Decorative objects |
Large structural parts Functional parts for household Industrial or engineering parts High-strength models |
Large structural parts Functional parts for household Industrial or engineering parts High-strength models |
*The final display of ‘Model Strength’ & ‘Model Fineness’ depend on the results of the material testing.
Filament Compatibility
Material |
0.2 mm Nozzle |
0.4 mm Nozzle |
0.6 mm Nozzle |
0.8 mm Nozzle |
Hardened Steel Required? |
General PLA |
YES |
YES |
YES |
YES |
Optional |
PLA Sparkle |
*NO |
YES |
YES |
YES |
Optional |
PLA Marble |
*NO |
YES |
YES |
YES |
Optional |
Wood/Rock/Metal-filled PLA |
*NO |
YES |
YES |
YES |
Optional |
PETG |
YES |
YES |
YES |
YES |
Optional |
PVA |
YES |
YES |
YES |
YES |
Optional |
ABS |
YES |
YES |
YES |
YES |
Optional |
ASA |
YES |
YES |
YES |
YES |
Optional |
PC |
YES |
YES |
YES |
YES |
Optional |
PA |
*NO |
YES |
YES |
YES |
Optional |
TPU |
*NO |
YES |
YES |
YES |
Optional |
Bambu PLA-CF |
*NO |
*Recommended |
YES |
YES |
Required |
Bambu PETG-CF |
*NO |
*Recommended |
YES |
YES |
Required |
Bambu PAHT-CF |
*NO |
YES |
*Recommended |
YES |
Required |
Bambu PET-CF |
*NO |
YES |
*Recommended |
YES |
Required |
CF/GF Filaments from other brands |
*NO |
Not Recommended |
YES |
YES |
Required |
[*Note]
* Filaments with carbon fiber, glass fiber, metal, or other inorganic particles are prone to clog a 0.2 mm nozzle.
* Bambu PLA-CF andBambu PETG-CF have been extensively tested and proven to have a low risk of clogging when printed with a hardened steel 0.4 mm nozzle, while also achieving higher print quality.
* For general carbon fiber or glass fiber filaments such as Bambu PAHT-CF and PET-CF, it isrecommended to use a hardened steel0.6 mm nozzle to minimize the risk of clogging and abrasion.
In the Box
– Hotend with Nozzle
Product Specifications
Max. Printing Temp. |
320 |
Length |
47.3 mm |
Packaging Weight |
30 g |
Packaging Size |
60*60*30 mm |
